Stand Alone  or Network Toxic and Explosive Gas Monitoring

Serving as the sensor in a gas detection network, the VA-201T provides accurate readings of toxic and explosive gas levels through its RS-485 communication link with the VA-201C Vulcain Controller, or directly back to a DDC or BMS through a 4-20mA output.

• Daisy chain installation
• 10-Step LED display
• DPDT alarm relay
• Audio alarm available
• Available in solid state, electrochemical, catalytic combustion and diffusion fuel cell sensing technologies
• Easy calibration
• Optional 4-20mA  and relay outputs
• Optional remote sensing and LCD display

• Power Requirements: 17-27 VAC, 24-38 VDC
• Concentration Display: 10-step LED
• Relay Contact Capacity: DPDT 1/8 HP, 5A 24dc or 240Vac
• Outputs: RS-485, relay and 4-20mA available
• Visual Indicators:        Yellow LED: Failure Indication
  Green  Led: Normal Operation
  Audible Alarm: 65dBA at 3 feet (1 metre)
• Humidity Range: 5-90%
• Operating Temperature:      32⁰ F to
  100⁰F (0⁰C  to 40⁰C)

Q1-Type Sensor

Electrochemical (toxic)             Catalytic Combustion (flammables)
Diffusion Fuel Cell (oxygen)

Q2-Type Sensor

Second Generation Oxide Semiconductor                     Solid-State

VA201T Toxic and Explosive Gas Transmitter

VA201D Industrial Toxic and Explosive Gas Transmitter

VA201C Controller

VASQN-8X Advanced Multi-Point Gas Monitor

90DM3A  CO₂   Gas Transmitte

Home

Description                                                                Part Number
Transmitter  with Q1-Type Sensor                                 VA-201T-Q1-xxx                 xxx: Gas to be detected
Transmitter  with Q2-Type Sensor                                 VA-201T-Q2-xxx                 xxx: Gas to be detected
Options:   4-20mA Output  (-C)   Relay Output (O)    Remote Sensor Configuration   ( -RS )
